FRONORD MAX PLUS

MD35DD-P301DDQ

Pharmacy refrigerator
FRONORD MAX PLUS

MD35DD-P301DDQ

Pharmacy refrigerator

Contactless control and register of temperature data and warnings

The CONTROLLA app makes it possible to connect to the refrigerator controller via a contactless network. This app also enables control over the refrigerator, while the user can download temperature reports and view alert history. The temperature in the refrigerator controller is recorded every 20 minutes.

Gross / Net capacity 350 / 230 L
Annual energy consumption 684 kWh
External dimensions (H x W x D) 1810 × 600 × 620 mm

Key Features

  • Temperature stability

The refrigerator is designed to maintain maximum stable temperature and minimal fluctuations. The maximum possible temperature change within the entire internal space of the refrigerator is only  2.9 °C.

  • +2 °C temperature limit

If the temperature drops below +2 °C for some critical reasons, the electronic controller immediately activates additional temperature maintenance functions along with a warning signal.

  • Warning register

Important data are recorded in the register: date of warning, duration, highest temperature. The last five warnings are stored in the controller memory.

  • Integrated data logger

The memory of the electronic controller stores the last five alarm records and a 6-month temperature measurement summary.

  • Warning of electricity supply failure

The battery provides sufficient energy for the registration of temperature readings and operation of the warning signal for the next 24 hours.

  • Warning temperature alarm

The integrated warning temperature alarm sends a warning signal with sound and image when temperature exceeds or falls below the set limit.

  • Display of minimum and maximum temperature

The maximum and minimum temperature values can be viewed directly on the electronic controller screen.

  • Cooling system with circulating air

The smart fan turns off when the door is opened and resumes when the door is closed, maintaining stable temperature conditions.

  • Calibration block

Calibration ensures that the measured internal air temperature matches the actual temperature of stored medical products.

Technical Information

Specification Value
Gross / Net capacity 350 / 230 L
Temperature range From +2 °C to +8 °C
Factory temperature setting +5 °C
Temperature fluctuation 0.5 °C
Gradient 2.9 °C
Annual energy consumption 684 kWh
External dimensions (H x W x D) 1810 × 600 × 620 mm
Noise level 50 dB(A)
Refrigerant R600a
Defrost Automatic
Interior lighting Ceiling LED light
