FRONORD MAX

MD40DD-P600SEQ

Pharmacy Refrigerator
FRONORD MAX

MD40DD-P600SEQ

Pharmacy Refrigerator

Professional pharmaceutical refrigeration solutions

FRONORD MAX pharmacy refrigerators are designed to ensure safe and reliable storage of medicines and pharmaceutical products. Built according to DIN 13277 requirements and tested under EN 60068-3 methodology, the MD40DD-P***SEQ series ensures advanced temperature stability and secure data monitoring.

Gross / Net capacity 385 / 290 L
Annual energy consumption 525 kWh
External dimensions (H x W x D) 2025 × 600 × 620 mm

Key Features

  • Temperature stability

The refrigerator maintains maximum stable temperature with only 2.9 °C fluctuation.

  • +2 °C temperature limit

If temperature drops below +2 °C, the controller activates additional protection functions and warning signals.

  • Integrated data logger

The controller stores up to 100 alarm records and temperature measurement summaries transferable to USB storage.

  • Warning of electricity supply failure

The internal battery supports warning signals and temperature registration for up to 12 hours during power outages.

  • Warning temperature alarm

Integrated audio and visual alarms notify users when temperature exceeds set limits.

  • Warning register

The controller stores detailed warning history including date, duration and highest temperature.

  • LAN interface

Integrated RS485 LAN interface allows digital monitoring and temperature documentation through external systems.

  • Access to an additional external sensor

12.5 mm access port allows installation of an external sensor without affecting sealing integrity.

  • Protection against contact with cold surfaces

Special evaporator protection prevents direct contact between medicines and cold surfaces.

  • Cooling system with circulating air

The smart fan system maintains stable internal temperature and minimizes rapid temperature changes.

  • Calibration block

Calibration ensures precise matching between measured air temperature and stored medication temperature.

  • Self-closing door

The self-closing system prevents accidental door opening and supports temperature stability.

Technical Information

Specification Value
Gross / Net capacity 385 / 290 L
Temperature range From +2 °C to +8 °C
Factory temperature setting +5 °C
Temperature fluctuation 0.5 °C
Gradient 2.9 °C
Annual energy consumption 526 kWh
External dimensions (H x W x D) 2025 × 600 × 620 mm
Noise level 50 dB(A)
Refrigerant R600a
Defrost Automatic
Interior lighting Ceiling LED light
